1SBL347001R1300
ABB AF40-30-00-13 is a high-performance 3-pole contactor designed for controlling power circuits and motors up to 18.5kW (400V). It is specifically engineered to handle a rated operational current of 40A (AC-3) and up to 70A (AC-1) for resistive loads, making it a versatile choice for industrial heating, pumping, and large ventilation systems.

Key Technical Features:

Advanced Electronic Coil: Operates seamlessly on any control voltage between 100V and 250V AC/DC, ensuring stable contact even in unstable power grids.

Superior Switching Capacity: Rated for heavy-duty applications with a focus on reducing energy consumption and heat dissipation.

Modular Configuration (00): Designed without built-in auxiliary contacts to provide a slim profile, allowing users to add specific auxiliary contact blocks as needed.

Built-in Surge Suppression: Features integrated protection against voltage spikes, eliminating the need for additional external suppressors.

1SBL367001R1300
ABB AF52-30-00-13 is a robust 3-pole contactor designed for reliable power switching and motor control up to 22kW (400V). Rated for an operational current of 53A (AC-3) and up to 100A (AC-1) for resistive loads, it is an essential component for large industrial pumps, compressors, and power distribution panels.

Key Technical Features:

Wide Control Voltage: The advanced electronic coil handles fluctuations between 100V and 250V AC/DC, ensuring stable operation and reduced inventory.

Integrated Protection: Built-in surge suppression comes standard, protecting sensitive electronic controllers and PLC outputs without the need for additional accessories.

Modular "00" Design: Contains no built-in auxiliary contacts, offering a compact frame that allows for the easy addition of front or side-mounted auxiliary contact blocks.

Energy Efficiency: The AF technology reduces coil energy consumption, leading to lower heat dissipation and increased cabinet density.

1SBL387001R1300
ABB AF65-30-00-13 is a high-capacity 3-pole contactor engineered for reliable motor control and power switching in heavy industrial environments. Specifically rated for 65A (AC-3) and capable of managing motors up to 30kW (400V), it is the ideal choice for large-scale industrial pumps, refrigeration compressors, and heavy machinery.

Key Technical Features:

Universal Control Voltage: Equipped with an advanced electronic coil operating between 100V and 250V AC/DC, effectively managing voltage sags and surges.

Heavy-Duty Power Handling: Supports resistive loads (AC-1) up to 105A, providing robust performance for power distribution and heating applications.

Modular "00" Frame: Features a compact design with no built-in auxiliary contacts, allowing for total customization with front or side-mounted auxiliary contact blocks.

Integrated Safety: Standard built-in surge suppression protects sensitive PLC and control outputs without the need for additional external components.

1SBL397001R1300
ABB AF80-30-00-13 is a high-capacity 3-pole contactor engineered for reliable motor control and power switching in heavy industrial environments. Specifically rated for 80A (AC-3) and capable of managing motors up to 37kW (400V), it is the ideal choice for large-scale industrial pumps, refrigeration compressors, and heavy machinery.

Key Technical Features:

Universal Control Voltage: Equipped with an advanced electronic coil operating between 100V and 250V AC/DC, effectively managing voltage sags and surges.

Heavy-Duty Power Handling: Supports resistive loads (AC-1) up to 125A, providing robust performance for power distribution and heating applications.

Modular "00" Frame: Features a compact design with no built-in auxiliary contacts, allowing for total customization with front or side-mounted auxiliary contact blocks.

Integrated Safety: Standard built-in surge suppression protects sensitive PLC and control outputs without the need for additional external components.

1SBL407001R1300
ABB AF96-30-00-13 is a high-performance 3-pole contactor engineered for heavy-duty motor control and power switching in demanding industrial environments. Specifically rated for 96A (AC-3) and capable of managing motors up to 45kW (400V), it is the premier choice for large-scale pumps, heavy machinery, and industrial compressors.

Key Technical Features:

Universal Control Voltage: Equipped with an advanced electronic coil that operates between 100V and 250V AC/DC, effectively managing voltage fluctuations and reducing inventory needs.

Heavy-Duty Power Handling: Supports resistive loads (AC-1) up to 130A, providing robust performance for power distribution and industrial heating.

Modular "00" Frame: Features a compact design with no built-in auxiliary contacts, allowing for total customization with front or side-mounted auxiliary contact blocks.

Integrated Safety: Standard built-in surge suppression protects sensitive PLC and control outputs without the need for additional external components.

1SBN010110R1001
ABB CA4-01 is a high-quality, front-mounted auxiliary contact block designed for the ABB AF contactor range. Featuring 1 Normally Closed (1NC) contact, this component is critical for creating electrical interlocks between two contactors (such as in Star-Delta or Forward-Reverse starters) and providing status feedback to control systems.

Key Features:

Snap-On Mounting: Attaches instantly to the front of the contactor without tools, ensuring a secure and vibration-proof connection.

Safety Interlocking: The 1NC configuration is the industry standard for preventing two contactors from closing simultaneously.

Broad Compatibility: Fully compatible with the AF09 through AF96 series, as well as the larger AF116 to AF370 models.

Industrial Durability: Built to withstand high-frequency switching cycles in demanding industrial environments.

1SBN010110R1010
ABB CA4-10 is a high-reliability, front-mounted auxiliary contact block designed for use with ABB AF series contactors. It provides 1 Normally Open (1NO) contact, allowing you to easily add signaling, interlocking, or status feedback to your electrical control panels.

Key Features:

Easy Installation: Features a simple "snap-on" front mounting mechanism—no tools required.

Universal Compatibility: Works seamlessly with AF09, AF12, AF16, AF26, AF30, AF38, and larger AF series contactors.

Reliable Performance: Engineered for industrial endurance with high-quality contact materials to ensure clear signal transmission.

Space Efficient: Front mounting keeps the contactor's width slim, saving valuable DIN rail space in your cabinet.

1SBN010120R1011
ABB CAL4-11 is a versatile, side-mounted auxiliary contact block designed for the AF series contactors. It provides 1 Normally Open (1NO) and 1 Normally Closed (1NC) contact in a single compact housing. This accessory is essential for complex control logic, allowing for simultaneous status signaling and electrical interlocking.

Key Features:

Side-Mount Design: Snaps easily onto either the left or right side of the contactor, preserving the front face for other accessories.

Dual Contact Configuration: Combines both an NO and an NC contact, providing total flexibility for motor control circuits.

High-Speed Integration: Features a tool-free installation process for fast assembly in industrial control panels.

Universal AF Compatibility: Designed to fit ABB contactors ranging from AF09 up to AF96 and the larger AF116-AF370 series.

1SBN010151R1011
ABB CAT4-11E is a specialized front-mounted auxiliary contact block featuring 1 Normally Open (1NO) and 1 Normally Closed (1NC) contact. Uniquely, it incorporates A1 and A2 coil terminals on the front of the block, allowing for streamlined wiring and easier access during maintenance. This "E" version is engineered for a perfect fit and logical terminal alignment with ABB's AF09 to AF16 series contactors.

Key Technical Features:

Integrated Coil Access: Moves coil terminal connections to the front, eliminating the need to reach behind power cables.

Dual Signaling Contacts: Provides both NO and NC contacts for status feedback and electrical interlocking.

Simplified Panel Layout: Reduces the complexity of control wiring, making it ideal for compact motor starter assemblies.

Quick Installation: Features the ABB snap-on mounting system for secure, tool-free attachment.

1SBN010151R1111
ABB CAT4-11M is a premium front-mounted accessory designed for the ABB AF series contactors. It is uniquely engineered to provide both 1 Normally Open (1NO) and 1 Normally Closed (1NC) auxiliary contacts while also featuring integrated coil terminals. This "M" (Master) version is designed to allow easy access to the coil connections from the front of the unit, significantly tidying up control panel wiring.

Key Technical Features:

Dual Purpose: Provides signaling/interlocking contacts and coil connection points in a single block.

Front-Facing Wiring: Moves the A1 and A2 coil connections to the front for easier maintenance and clearer wire routing.

Seamless Integration: Designed specifically for AF09, AF12, AF16, AF26, AF30, and AF38 contactors.

Standard Industrial Quality: Built to withstand harsh environments with high mechanical and electrical endurance.

1SAX121001R1101
ABB EF19-0.32 is an advanced electronic overload relay designed for the most precise motor protection. With an adjustable setting range of 0.10 to 0.32 Amperes, it is specifically engineered to protect small motors against overloads and phase failures. Because it is electronic, it provides consistent trip classes (10E, 20E, 30E) and consumes significantly less energy than traditional thermal relays.

Key Technical Features:

Precision Protection: Offers a wide 3.2:1 setting range, allowing one device to cover multiple motor sizes.

Selectable Trip Classes: Choose between 10E, 20E, or 30E to match the starting characteristics of your specific load.

Phase Loss Sensitivity: Rapidly detects phase imbalance or failure to prevent motor burnout.

Self-Powered: No external power supply is required for the control circuit.

Direct Mounting: Designed for direct attachment to AF09, AF12, AF16, AF26, AF30, and AF38 contactors.

1SAX121001R1102
ABB EF19-1.0 is a high-performance electronic overload relay designed for the precise protection of small motors. Covering a setting range of 0.30A to 1.0A, this relay offers a modern alternative to traditional bimetallic thermal relays. Because it utilizes electronic sensing, it is not affected by ambient temperature, providing consistent and reliable tripping to prevent motor damage from overloads and phase failures.

Key Technical Features:

Superior Accuracy: Electronic current measurement provides tighter protection tolerances compared to standard thermal relays.

Selectable Trip Classes: Offers flexibility with adjustable trip classes (10E, 20E, 30E) to protect motors during difficult or heavy startups.

Phase Loss Protection: High sensitivity to phase imbalance ensures the motor is disconnected quickly if a phase is lost.

Energy Efficient: Designed with extremely low internal power consumption, reducing heat buildup inside your control cabinet.

Contactor Compatibility: Mounts directly to AF09, AF12, AF16, AF26, AF30, and AF38 3-pole contactors.

1SAX121001R1105
ABB EF19-18.9 is a self-supplied, high-accuracy electronic overload relay designed for the comprehensive protection of motors ranging from 5.70 to 18.90 Amperes. By utilizing advanced electronic sensing, it provides superior protection against overloads, phase failures, and phase imbalances. It is the ideal energy-efficient upgrade for control panels using ABB AF contactors.

Key Technical Features:

Broad Setting Range: A 3.3:1 adjustment ratio (5.7-18.9A) allows one unit to cover a wide variety of motor horsepowers.

Flexible Trip Class Selection: User-selectable trip classes (10E, 20E, 30E) ensure the relay can handle standard or heavy-duty motor starts without nuisance tripping.

Ambient Temperature Independence: Unlike thermal relays, the EF19-18.9 maintains its accuracy even in hot industrial cabinets or fluctuating environments.

Integrated Safety: Features a built-in trip indicator and a test/stop button for rapid troubleshooting and maintenance.

Direct Contactor Mount: Fits perfectly onto the load side of AF09, AF12, AF16, AF26, AF30, and AF38 contactors.

1SAX121001R1103
ABB EF19-2.7 is an advanced electronic overload relay engineered for reliable and precise motor protection. Featuring an adjustable range of 0.80 to 2.70 Amperes, it is the perfect solution for protecting small motors against overloads, phase failures, and phase imbalances. Unlike standard thermal relays, the EF19 series remains accurate regardless of ambient temperature and offers adjustable trip classes.

Key Technical Features:

Precision Current Setting: Covers a wide range from 0.80A to 2.70A, providing high flexibility for different motor ratings.

Adjustable Trip Classes: Choose between 10E, 20E, and 30E to match the specific starting requirements of your load.

Phase Loss Sensitivity: Advanced electronic sensing detects phase imbalance or loss much faster than traditional bimetallic relays.

Low Power Consumption: Minimizes energy loss and heat dissipation, keeping control panels cooler and extending component life.

Direct Mounting: Designed for seamless direct attachment to the bottom of AF09, AF12, AF16, AF26, AF30, and AF38 contactors.

1SAX121001R1104
ABB EF19-6.3 is a precision electronic overload relay engineered for superior motor protection. With an adjustable setting range of 1.90 to 6.30 Amperes, it provides high-accuracy protection against overloads, phase failures, and phase imbalances. Utilizing electronic sensing technology, the EF19-6.3 ensures reliable tripping and offers selectable trip classes to accommodate various motor starting conditions.

Key Technical Features:

Precision Sensing: Offers a 3.3:1 setting range (1.9-6.3A), allowing one relay to cover multiple motor sizes with electronic accuracy.

Selectable Trip Classes: Easily adjustable between 10E, 20E, and 30E to protect motors during normal or heavy starting sequences.

Temperature Independence: Electronic measurement remains stable and accurate regardless of the heat inside the electrical cabinet.

Phase Loss Sensitivity: Rapidly detects phase loss or imbalance to prevent motor winding damage.

Direct Mounting: Designed for quick and easy direct connection to AF09, AF12, AF16, AF26, AF30, and AF38 contactors.

1SAX221001R1101
ABB EF45-30 is a state-of-the-art electronic overload relay engineered to protect motors from 9.0 to 30.0 Amps. Specifically optimized for use with AF26, AF30, and AF38 contactors, it offers a wider setting range and higher accuracy than traditional bimetallic relays. With its ability to handle different trip classes, it is the ideal choice for protecting pumps, fans, and conveyors in demanding industrial environments.

Key Technical Features:

Extended Setting Range: The 9.0–30.0A range allows for versatile application across various motor sizes with a single device.

Selectable Trip Classes: Features adjustable trip classes (10E, 20E, 30E), providing tailored protection for both standard and heavy-duty motor starts.

Advanced Phase Loss Protection: Electronics-based sensing ensures rapid tripping in the event of phase failure or imbalance, preventing motor burnout.

Temperature Compensated: Maintaining its trip curve regardless of ambient temperature changes, ensuring reliable protection in hot control rooms.

Low Energy Consumption: Reduces internal heat generation by up to 50% compared to thermal relays, increasing the lifespan of your control cabinet components.

1SAX221001R1102
ABB EF45-45 is a high-performance, self-supplied electronic overload relay engineered for superior protection of industrial motors. With an adjustable setting range of 15.0 to 45.0 Amperes, it is the perfect match for AF26, AF30, and AF38 contactors when operating at higher power levels. Its electronic design ensures that the trip curve remains stable and accurate, providing a massive upgrade in reliability over standard bimetallic relays.

Key Technical Features:

Broad 45A Setting Range: A 3:1 adjustment ratio (15-45A) provides exceptional flexibility for a wide variety of motor horsepowers and industrial loads.

Customizable Protection: Selectable trip classes (10E, 20E, 30E) allow you to protect motors with easy starts or high-inertia, heavy-duty starts.

Superior Phase Failure Protection: Fast-acting electronic sensors detect phase loss or imbalance in milliseconds, preventing catastrophic motor winding failure.

Eco-Friendly Energy Efficiency: Features significantly lower power loss compared to thermal relays, reducing heat generation in high-density electrical panels.

Rugged Reliability: Built to operate in harsh industrial environments with a design that is immune to ambient temperature fluctuations.

1SAZ721201R1005
ABB TF42-0.13 is an economical and reliable protection device for the main circuit. It is designed to protect small motors and sensitive electrical loads in the event of overload or phase failure. With a precise setting range of 0.10 to 0.13 Amperes, this relay is a critical safety component for specialized low-power industrial equipment.

Key Technical Features:

Bimetallic Protection: Features a Class 10 trip characteristic for dependable thermal protection.

Temperature Compensation: Operates accurately in ambient temperatures ranging from -25°C to +60°C.

Phase Failure Sensitivity: Built-in mechanism to detect phase loss, preventing motor damage under unbalanced conditions.

Multifunctional Reset: Includes a Reset button that can be switched between Manual and Automatic modes, plus a Test and Stop function.

Direct Contactor Mounting: Designed to plug directly into the load side of AF09, AF12, AF16, AF26, AF30, and AF38 3-pole contactors.

1SAZ721201R1008
ABB TF42-0.17 is an economical and robust motor protection solution. Specifically calibrated for a current range of 0.13 to 0.17 Amperes, it provides essential thermal protection (Class 10) for micro-scale industrial loads. Part of the proven TF42 series, it is engineered to mount directly to AF contactors, creating a compact and efficient motor starter.

Key Technical Features:

Reliable Bimetallic Protection: Features a Class 10 trip curve to prevent motor overheating and winding damage.

Phase Failure Sensitivity: Built-in protection mechanism that responds quickly to phase loss or imbalance.

Operational Versatility: Equipped with a multifunctional reset button (Manual/Auto), a Test function, and a Stop button for system diagnostics.

Ambient Temperature Compensation: Designed to maintain accuracy in variable environments ranging from -25°C to +60°C.

Direct Contactor Mounting: Saves panel space and wiring time by plugging directly into AF09, AF12, AF16, AF26, AF30, and AF38 contactors.

1SAZ721201R1009
ABB TF42-0.23 is an economical and highly reliable protection device for the main motor circuit. It is engineered to protect small-scale motors in the event of overload or phase failure. With a specialized adjustable range of 0.17 to 0.23 Amperes, this relay provides Class 10 tripping characteristics, making it an essential safety component for high-precision industrial machinery.

Key Technical Features:

Bimetallic Thermal Protection: Proven Class 10 trip characteristic to prevent winding damage during overcurrent events.

Phase Loss Sensitivity: Built-in mechanism detects phase imbalance or loss, triggering a trip to protect the motor.

Ambient Temperature Compensation: Ensures accurate tripping performance in temperatures ranging from -25°C to +60°C.

Versatile Control: Features a selectable Manual/Automatic reset, a Test function for circuit verification, and a Stop button.

Direct Contactor Integration: Specifically designed for direct mounting to the underside of AF09, AF12, AF16, AF26, AF30, and AF38 contactors.
